EDM Cutting Process

Wire Electrical Discharge Machining (Wire EDM) is an important technology. It gives near-perfect accuracy and usefulness beyond comparison. It produces some incredibly precise parts with incredibly tight fits and dimensions by carefully controlling the vaporisation of metal using electrical discharge.This machining process is widely used by makers of parts in various industries and comes highly recommended in CNC machining shops. This article will cover wire EDM cutting, materials that work with it, and its applications in various industries.

EDM Cutting Process

The wire EDM cutting process involves several key steps, including setup, flushing and die sinking, spark erosion, and wire path and guidance system. Here is a detailed explanation of the EDM cutting process:

Setup

The setup of an EDM machine is crucial for achieving accurate and precise results. It involves the following steps:

• Workpiece Preparation: The workpiece, often made of conductive materials like metals, is prepared according to the desired dimensions and shape. It is essential to ensure that the workpiece is securely clamped to the machine to prevent movement during the EDM process.
• Tool Electrode Selection: The tool electrode, typically made of a conductive material. like copper or graphite, is chosen based on the specific material and intricacy of the workpiece. The tool electrode is the negative electrode in the EDM process.
• Dielectric Fluid Selection: A dielectric fluid, usually a specialized EDM oil, is used to facilitate the electrical discharge and to cool the workpiece and tool electrode. The dielectric fluid also helps flush the removed material from the cutting zone.
• Setting Parameters: Parameters such as current, voltage, pulse duration, and gap distance are set based on the material properties of the workpiece and tool electrode. These parameters determine the intensity and time of the electrical discharges.



Flushing and Die Sinking:

This step involves the continuous dielectric fluid supply to the gap between the tool electrode and the workpiece. The dielectric fluid serves multiple purposes: it acts as a coolant, removes debris from the cutting zone, and helps conduct electrical discharges.

In die-sinking EDM, the tool electrode is gradually brought closer to the workpiece. This controlled approach is crucial for maintaining a consistent spark gap distance and ensuring a uniform material removal rate.

Spark Erosion:

Once the setup is complete and the dielectric fluid flows, the EDM machine begins the spark erosion. This is the heart of the EDM cutting process. It involves generating a series of controlled electrical discharges between the workpiece and tool electrode.

• Electrical Discharge: When a high-frequency electrical pulse is applied, a spark or electrical discharge occurs between the tool electrode and the workpiece. This generates extremely high temperatures, causing localized melting and vaporization of the material.
• Material Removal: The intense heat of the electrical discharge causes small particles of the workpiece material to be removed, resulting in the desired shape. The dielectric fluid helps to flush away these particles, preventing them from accumulating and affecting the process.

Wire Path and Guidance System:

In wire EDM, a thin, electrically conductive wire is used as the tool electrode. This wire is guided along a programmed path to create intricate shapes. The wire path and guidance system are critical components of the EDM machine.

• Wire Tensioning: The wire is tightly strung between two spools and kept under constant tension to ensure accurate and consistent cutting.
• Guidance System: The EDM machine is equipped with a sophisticated guidance system that precisely controls the movement of the wire along the programmed path. This system ensures the wire accurately follows the desired shape, allowing for intricate and complex cuts.
• Automatic Wire Threading: Modern EDM machines often have automatic wire threading systems that facilitate the wire threading through the workpiece.
